AR6 5,5/6,3xL

Self-drilling screws for fastening sandwich panels to cold-formed steel structures

Self-drilling screws with double thread, made of hardened carbon steel, with hexagonal head andaluminium EPDM washer

Product description

Material

carbon steel SAE 1022

Head size

8 mm

Corrosion protection

Eco-GrePert™ coating

Corrosion resistant class

C4

EPDM washer

aluminium Ø19 - A9

Powder coating

UV-resistant polyester coating, 50-60 µm thick,
color-matched to the roof covering

Application

fastening of sandwich panels

Substrate

cold-formed steel structure

ETA

ETA-19/0586

Specification

index diameter length washer MTmin MTmax single pack
d [mm] L [mm] Ø mm mm pcs
P65565EGA9 5,5/6,3 65 19 27 47 100
P65590EGA9 5,5/6,3 90 19 32 72 100
P655110EGA9 5,5/6,3 110 19 45 92 100
P655125EGA9 5,5/6,3 125 19 60 107 100
P655150EGA9 5,5/6,3 150 19 65 132 100
P655175EGA9 5,5/6,3 175 19 90 157 100
P655200EGA9 5,5/6,3 200 19 115 182 100
P655230EGA9 5,5/6,3 230 19 145 212 100
P655275EGA9 5,5/6,3 275 19 190 257 100
P655320EGA9 5,5/6,3 320 19 235 302 100

8mm icon
RAL
zakładowa kontrola produkcji
CE

Installation recommendations

Minimum substrate thickness Tmin

1,5 mm

Magnetic adapter

M8

Max drilling capacity DC

6 mm

Recommended tightening torque

ok. 5 Nm

Screw installation perpendicular to the substrate with approx. 1500 rpm

Screwdriver with adjustable torque setting

Downloads

Product specification sheet

AR6 5,5/6,3xL

download icon
Technical Assessment

ETA-19/0586

download icon
Declaration of performance

DoP-19-0586

download icon
Certificate of conformity

1488-CPR-0569/Z

download icon
Hygenic certificate

HC

download icon
